Tangential Chasers

Tangential Chasers

We are an Exporter of Tangential Chasers, used for external threading of components that are hard to roll, such as big bolts, Fasteners, or pipes. Tangential chasers are made for all threading standards and die head sections in 4 and 6 pieces sets. The cutting of thread is made in Thread Cutting Machines.
Our Tangential Chasers are made from high-quality raw materials and advanced technology for more extended performance. These chasers are made as Multi profiles and allow cutting thread in one step to full deepness. The chasers are exported by us to various countries worldwide.

The thread-cutting heads have moveable chasers, which cut the thread constantly in product material to the requested diameter of the thread. After the finish of the thread, the head is opened, and the product is given out. The Tangential chasers are also known for accurate thread profiles and correct parameters with respect to fitting and setting on die heads.

NOTE: Available in standard as well as non -standard sizes as per requirement.

Features
  • Durable
  • Efficient Performance
  • Dimensional accuracy
  • Low maintenance
  • Cost-effective
    Technical Specification:
  • Material: HSS M2, M35, M42
  • Available in set of 4 and 6 pieces
  • Common Thread Pitch: 1, 1.25, 1.5, 1.75, 2, 2.5, 3, 3.5, 4
  • Thread Form: BSW, BSF, BSP, Metric, NPT, BSPT, UNG, UNF, NGT.
  • Application/Usage: used for cutting of thread with tangential cutting heads.
  • Available in length from 1” to 6” according to the size of the die head
  • Highly corrosion resistance
