HSS Keyway Broach Set (Inch)

HSS Keyway Broach Set (Inch)

DIC Tools is a Manufacturer and Exporter of HSS Keyway Broaches Sets (Inch) available with all types of Standard PVD Coatings. Keyway Broach set includes multiple Keyway Broaches in a wide range of sizes which are used for creating precise keyways in boreholes of pulleys, gears, and Washers. It also contains shims for controlling the depth of the keyway.

Also, Keyway Broaches set eliminates the problem of individual tools separately and are ideal for jobs that frequently use many different sizes of keyway broaches. Our Broach sets include the most common combinations of Metric Keyway Broaches and Bushings.

    INCH SIZE HSS KEYWAY BROACHES SET:
  • NO.00 KEYWAY BROACH SET: 3 broaches and 5 bushings= 15 keyway combinations
  • NO.10 KEYWAY BROACH SET: 4 broaches and 9 bushings= 18 keyway combinations
  • NO. 10A KEYWAY BROACH SET: 4 broaches and 9 bushings= 18 keyway combinations
  • NO. 20 KEYWAY BROACH SET: combines 10 and 10A but adds a 5/16 inch keyway for 11 extra combinations, 5 broaches and 18 bushings = 47 keyway combinations.

    SPECIFICATIONS AND FEATURES:
  • Material: HSS M2, M35, M42, HSS4341, ASP 2030, ASP 2052, ASP 2062
  • The most common keyway combinations for small keyways and bores. 4 Broaches and 9 bushings= 18 keyway combinations.
  • Smallest Broach set: 1/16 – 5/16
  • Largest Broach Set: 1/8”-1/2”
  • Available with all types of PVD Coatings
  • Type: Inch type
NO.00 KEYWAY BROACHES SET
Keyway SizeBroach StyleBushing Dia.
1/16"A1/4,5/16, 3/8, 7/16, 1/2"
3/32"ACOLLARED BUSHINGS
1/8"A-

NO.10 KEYWAY BROACHES SET
Keyway SizeBroach StyleBushing Dia.
1/8"B1/2, 5/8"
3/16"B3/4, 7/8"
1/4"C1, 1-1/8"
3/8"C1-1/4, 1-3/8, 1-1/2"
COLLARED BUSHINGS

NO.10 A KEYWAY BROACHES SET
Keyway SizeBroach StyleBushing Dia.
1/8"B9/16"
3/16"B11/16, 13/16"
1/4"C15/16, 1-1/16,1-3/16"
3/8"C1-5/16, 1-7/16,
COLLARED BUSHINGS

NO.20 KEYWAY BROACHES SET
Keyway SizeBroach Style1/2,9/16,5/8,11/16"
1/8"B1/2, 9/16,5/8, 11/16"
3/16"B3/4, 13/16, 7/8"
1/4"C15/16, 1-1/16,1-3/16"
5/16"C1-1/4, 1-5/16,1-3/8"
3/8"C1-7/16,1-1/2,1-9/16"
COLLARED BUSHINGS
