HSS Square Push Broaches (Inch)

HSS Square Push Broaches (Inch)

DIC is Manufacturer and Exporter of HSS Square Push Broaches (Inch), usually designed to generate a standard square hole in one pass in a previously done round hole. It is manufactured from HSS material in grades M2, M35, M42, ASP 2030, ASP 2052, and ASP 2062. Our range of Square Push Broaches is ideal for cutting accurate square forms in metal products by using a pilot hole and required Broach. Each tooth of Broach is progressively larger, and each cuts slightly deeper than the tooth before. These square broaches are available in Inch Size. It is well suited for use in a variety of ferrous and non-ferrous materials.

    SPECIFICATIONS AND FEATURES:
  • Material: HSS M2, M35, M42, ASP 2030, ASP 2052, ASP 2062.
  • Hex Size: 1/8" to 1"
  • Tolerance: .1250” to 1.003”
  • Broach Length: 4-1/8" to 24-1/8"
  • Pilot Dia.: .1285" to 1.0938"
  • Minimum length of cut: 3/16" to 1/2"
  • Maximum length of cut: 1/2" to 2"
  • Can be supplied with all types of coatings
  • Well suited for use in a variety of ferrous and non-ferrous material
  • Type: Inch
HSS Hexagon Push Broaches (Inch)LENGTH OF CUT
Hex SizeToleranceBroach LengthPilot Dia.Drill SizeMin.Max.
1/8".1250"-.1260"4-1/8".1285"-3/16"1/2"
5/32".1565"-.1575"5-1/8".1590"-1/4"1/2"
3/16".1880"-.1890"5-9/16".1935"-1/4"5/8"
7/32".2190"-.2200"6-3/8".2280"-1/4"3/4"
1/4".2505"-.2515"6-1/2".2656"17/64"1/4"3/4"
9/32".2815"-.2825"7-3/4".2969"19/64"5/16"1"
5/16".3130"-.3140"7-7/8".3281"21/64"3/8"1"
11/32".3440"-.3450"9-3/8".3594"23/64"3/8"1-1/4"
3/8".3775"-.3765"9-3/8".3906"25/64"3/8"1-1/4"
13/32".4065"-.4075"10-5/8".4219"27/64"1/2"1-3/8"
7/16".4385"-.4395"10-7/8".4531"29/64"1/2"1-3/8"
15/32".4690"-.4700"12".5000"1/2"1/2"1-3/8"
1/2".5005"-.0515"12".5312"17/32"1/2"1-3/8"
9/16".5630"-.5640"14-3/4".5938"19/32"1/2"1-1/2"
5/8".6260"-.6270"16-5/16".6562"21/32"5/8"1-5/8"
11/16".6885"-.6895"B17-3/4".7500"3/4"5/8"1-5/8"
3/4".7510"-.7520"17-3/4".8125"13/16"5/8"1-5/8"
7/8".8765"-.8775"22-3/4".9395"15/16"1/2"2"
1"1.002"-1.003"24-1/8"1.0938"1-3/32"1/2"2"
